Product Information

concrete pump is a kind of multi-functional pump, it can realize the concrete mixing and conveying at the same time. It also can named cement mixer and pump. concrete pump has the characteristics of high working efficiency. It conveys the concrete by using the pressure along the pipeline continuously to the construction site where need concrete mixture. So concrete mixer and pumping machine is a perfect combination between the concrete mixing and concrete conveying, which has the features of high efficiency, easy moving, low cost, etc.

Haomei machinery mainly provideconcrete pump with the models of EMP40, DMP4, DMP50. EMP is electirc engine, and DMP is diesel engine. You can see the details from the parameter tables.

Parameter		Unit	DMP50
Power		kw	Weichai diesel engine; 66kw
Whole machine	Length	mm	4680
	Width	mm	2100
	Height	mm	2300
	Weight	kg	4200
Mixer	Mixer model	/	JZM450
	Theoretical mixing capacity	m3/h	15-25
	Maximum aggregate size	mm	40
	Working cycle time	s	72
	Feeding height	mm	1400
	Hopper capacity	m3	0.65
Pumping system	Theoretical pumping capacity	m3/h	45
	Theoretical pumping pressure	MPa	10
	Delivery cylinder	/	230*800
	Hydraulic system	/	concrete pump New | concrete mixer with pump concrete pump Twin shaft and planetary mixers for concrete batch plants. Pre-wired, pre-plumbed and factory tested. View Details $3474.00 Adds product to compair Add to C5 mobile diesel concrete mixer with pump New | concrete mixer with pump haomei machinery offers customers with various types of concrete mixing equipment, C5 mobile diesel concrete mixer with pump,including two-shaft compulsory mixers, vertical shaft planetary mixers, truck mixers, View Details $4235.00 Adds product to compair Add to self loading concrete mixer with pump New | concrete mixer with pump Our self loading concrete mixer with pump is a modern mechanical equipment, which can mix cement, aggregate and water into a concrete mixture with certain ratio. View Details $1007.00 Adds product to compair Add to Used Concrete Mixer Pump Trucks for sale New | concrete mixer with pump Used Concrete Mixer Pump Trucks for sale is applicable to large, medium-sized, and small component factories and roads, bridges, water conservancy, ports, and other industrial or civil constructions. It is a high efficient machine with extensive appl View Details $4328.00 Adds product to compair Add to portable diesel concrete mixer with pump New | concrete mixer with pump we are the professional portable diesel concrete mixer with pump supplier in China, any need,please contact us! wade@haomei.biz View Details $7327.00 Adds product to compair Add to portable concrete pump New | concrete mixer with pump portable concrete pump are another option for mixing applications. This type of mixer is designed to stay in place while concrete is being poured. View Details $5919.00 Adds product to compair Add to used concrete mixer with pump for sale Add to $5041.00 concrete pump Add to $3474.00 Concrete Pumping Machine For Sale Add to $4989.00 electric generator concrete mixer pump Add to $8721.00 trailer concrete mixer pump Add to $8256.00 Small Portable Concrete Pumping Machine Add to $8356.00 Contact Details Email:Mail:info@hmconcreteplant.com Email:Mail:wade@haomei.biz Tel (86) 371-6562-1392 Fax (86) 371-8661-6825 web:concrete-machine.com Send your message to US Send Messages ACCOUNT concrete plant concrete mixer concrete pump concrete truck asphalt plant Contact INFORMATION CONTACT REGISTRATION LEGAL NOTICE TERMS AND CONDITIONS FAQ CONTACT US Tel:+86-371-65621392 Fox:+86-371-86616825 Mail:info@hmconcreteplant.com Mail:wade@haomei.biz SOCIAL MEDIA © concrete machine Online
