concrete mixer truck types

-

1047 items in Type


Haomei is China concrete mixer truck types manufacturer. A concrete truck mixer or called a concrete transport truck/in-transit mixer are made to transport

More Details

Product Information

 The concrete mixer truck types is a main equipment of construction machinery during commercial concrete transportation and deposition.
concrete mixer truck types has the advantages of flexibility, high efficiency and good pouring quality, so it plays an important role in infrastructure construction and national economic development

haomei machinery concrete mixer truck types belongs to a special truck, which is used to transport ready-mix concrete in construction projects. Our concrete mixer truck has the dual function of transportation and agitation, which can be transported to ensure the quality of concrete delivery and achieve concrete delivery of high-performance and all mechanized operations within a certain distance. Our concrete mixer truck includes chassis and special concrete equipment for mixing and transportation, and it is widely used in urban construction, highways, railways, utilities and other concrete construction projects. In addition, the use of concrete mixer truck greatly improves labor productivity and construction quality.



Model   HM6-D HM8-D HM9-D HM10-D HM12-D HM14-D HM16-D
Specification Unit HM6-D HM8-D HM9-D HM10-D HM12-D HM14-D HM16-D
Mixing Capacity  6 8 9 10 12 14 16
Tank Volume 9.96 12.8 14.7 17.05 17.93 20.1 24.1
Feeding Speed m³/min ≥3 ≥3 3.5 3.5 3.5 3.5 3.5
Discharging Speed m³/min ≥1.5 ≥1.5 ≥3 ≥3 ≥3 ≥3 ≥3
Residual Ratio of Discharging % 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%
Water Supply System   Air pressure Air pressure Air pressure Air pressure Air pressure Air pressure Air pressure
Water Tank Volume L 260 260 300 300 400 400 400
Overall Dimension mm 8450*2496*3835 8715*2496*3800 9050*2496*3750 9050*2496*3750 9880*2496*3920 10300*2496*3920 10850*2496*3980
Chassis Model   Steyr HOWO HOWO HOWO HOWO HOWO HOWO
Clutch φ φ430 Monolithic dry type φ430 Monolithic dry type φ430 Monolithic dry type φ430 Monolithic dry type φ430 Monolithic dry type φ430 Monolithic dry type φ430 Monolithic dry type
Min Ground Clearance mm 297 314 314 314 245 245 245
Max Speed  km/h 75 90 90 90 86 90 90
Engine Max Output Power kw 247 276 276 276 340 340 340
Emission Standard   Euro Euro Euro Euro Euro Euro Euro
Rated Load kgs 12600 13500 13500 13500 15000 16000 16600
Overall Weight kgs 25000 25000 25000 25000 25000 31000 31000
Wheelbase mm 3225+1350 3225+1350 3825+1350 3825+1350 4025+1350 1800+3200+1350 1800+3600+1350



concrete mixer truck types Advantages

1. Fast unloading speed, 0.43cbm/ R, conventional 0.35cbm/r, 19% higher than the average product
2. Mixing evenly, special blade spiral design, to achieve three-dimensional mixing of concrete, mixing evenly, no segregation, (no segregation, determines the quality of the building works)
3. Complete discharge, the residual rate is 0.4%, the average product is 0.6%, 33% higher than the average product
4. Mechanical agitation use wear-resisting material, in the easy wearing part uses the wear-resisting material to strengthen, generally the tank body uses 5-8 years. Quick feeding and unloading, mixing evenly, no segregation, complete discharge, low residual rate, good after-sales service, large loading capacity.
